30W 40W 60W Laser Marking And Engraving Machine For Wood / Paperboard

  • 1
  • 2
  • 3

Place of Origin : Wuhan,China

Brand Name : COTAJET

Certification : CE,Rohs,SGS

Delivery Time : 5-7 work day

Payment Terms : TT,L/C,Western union

Model Number : CL200B

Material : printing on Paperboard

Product Tags : CO2 Laser Marking Machine

Laser Power : 30W/40W/60W

Marking speed : ≤12000mm/s

Laser wavelength : 9.30um/10.2um/10.6um

Controller : 10.2 inch touch controller

Product ID : CL200B

Marking range : 110X110mm(Standard) Optional:150X150mm,300X300mm

Production line speed : 0~130m/min (depending on the material)

Name : Laser Marking And Engraving Machine

Contact Now

Laser Marking and engraving machine for wood and Paperboard



3-Axis Beam Control

Three-dimensional control enables marking on non-flat surfaces such as cylinders, slopes, and stepped shapes. It also simplifies product and tooling changeovers. The wide 300 x 300 mm area can efficiently mark and process products simultaneously, helping reduce equipment costs.





project

Parametertable

CO2-30W

CO2-40W

CO2-60W





characteristic

Machine   material

All aluminum   sandblasting oxidation

Laser

The service   life is more than20000-30000 hours

Laser   wavelength

1060nm

output power

≥38W

≥43W

≥70W

Marking   speed

≤12000mm/s

controller

10.2 inch   touch controller

Cooling   system

Air cooling







parameter

Focus lens

145mm

Minimum   linewidth

0.03mm

Repetitionaccuracy

0.01mm

Marking   range

110mm*110mm(optinal)

Number of   rows

Any line   within the marking range

Production   line speed

0~130m/min   (depending on the material)









Software

Multilingual

English,   Spanish, German, Chinese, Russian, Arabic, etc

jurisdiction

Multi user   management authority

operating   system

Linuxsystem

Inkjet mode

Static,   analog, encoder

Reserved   signal

Start, print   status, finish, fault

data   protection

With power   failure data protection energy

monitor

Provide   overspeed alarm function

De crossing

Automatic   removal of intersections

Coding   software

Single and   double machine code sending



Support type

typeface

Chinese and   English, numbers, traditional, etc

file format

BMP/DXF/HPGL/JPEG/PLT

bar code

CODE39,CODE128,CODE126,QR



Servicing   parameters

Power Supply

220V/50HZ

Power consumption

800W

Net weight   of machine

45kg

Overall   dimension

nose:666mmX165mmX157mm

environment

requirement

External   temperature0℃－45℃;humidity≤95
